ACT Alignment Tool

1997–2009 Audi A4 / A4 Quattro / A6 Quattro / S4 / RS4 / Volkswagen Passat 2.0L–3.0L

Part #: AT36

Overview

The ACT Alignment Tool AT36 is an essential accessory designed to simplify the installation of ACT pressure plates and clutch assemblies on compatible vehicles. Specifically engineered for models such as the Audi A4, A4 Quattro, A6 Quattro, S4, RS4, and Volkswagen Passat from the late 1990s through the mid-2000s, this tool ensures precise alignment of the clutch disc with the pilot bearing, making your clutch replacement process smoother and more efficient.

If you're a DIY enthusiast or a professional mechanic working on these vehicles, the ACT Alignment Tool AT36 provides a reliable solution to reduce installation time and prevent common misalignment issues. Proper alignment is critical for ensuring the longevity and performance of your clutch components, and this tool guarantees that your clutch assembly is perfectly centered, reducing the risk of uneven wear or damage.

Key Features

The ACT Alignment Tool AT36 offers a range of features tailored for ease of use and durability:

• Precisely machined from high-quality materials to ensure durability and accurate alignment during clutch installation.
• Designed specifically for the spline diameter of 0.9375 inches (23 splines), matching the input shaft of the specified vehicles.
• Lightweight construction, weighing only 0.1 lbs., making it easy to handle and store.
• Compatible with a wide range of models, including Audi and Volkswagen vehicles from 1997 to 2009, covering various engine sizes and configurations.
• Facilitates correct positioning of the clutch disc relative to the pilot bearing, ensuring optimal engagement and smooth operation.
• Simple to use—just insert the tool into the clutch assembly to hold the disc in perfect alignment during installation.
• Reduces installation time and minimizes the risk of damaging the clutch components or misaligning the assembly.
• Manufactured by ACT, a trusted name in high-performance clutch components and accessories, ensuring quality and reliability.
• Designed for both professional mechanics and experienced DIYers seeking a straightforward, effective solution for clutch installation.

Construction & Design

The ACT Alignment Tool AT36 is crafted from durable, precision-machined metal to withstand the rigors of automotive repair. Its compact design allows for easy handling and insertion into the clutch assembly, providing a stable guide for the clutch disc during installation. The tool's spline diameter of 0.9375 inches (23 splines) ensures a perfect fit with the input shafts of the compatible vehicles, including various Audi and Volkswagen models.

Its lightweight construction does not compromise strength, making it easy to maneuver in tight engine bays. The high-quality materials and manufacturing processes used in its production guarantee long-lasting performance, even after multiple uses. The design emphasizes simplicity and effectiveness, allowing users to achieve precise alignment without the need for additional tools or complicated procedures.

Installation & Fitment

The ACT Alignment Tool AT36 is designed for straightforward, bolt-on use. To install, simply insert the tool into the clutch assembly after placing the clutch disc onto the input shaft. The tool holds the disc in perfect alignment with the pilot bearing, allowing you to easily bolt the pressure plate in place without worry of misalignment. No additional adjustments or special tools are required.

This alignment tool is compatible with a variety of vehicles, including:

• 2000-2009 Audi S4
• 1997-2005 Audi A4 Quattro
• 2000-2004 Audi A6 Quattro
• 1997-2008 Audi A4
• 1998-2005 Volkswagen Passat
• 2007-2008 Audi RS4

Its universal spline fit and simple design make it an invaluable tool for ensuring proper clutch alignment, which is critical for optimal clutch performance and longevity. The process is quick, clean, and requires no special modifications or adjustments.

What's Included

• ACT Alignment Tool AT36, precisely machined for durability and accuracy

Ideal For

• DIY enthusiasts performing clutch replacements on Audi and Volkswagen models from 1997 to 2009
• Professional mechanics seeking a reliable, time-saving tool for clutch installation
• Anyone looking to ensure perfect clutch disc alignment for optimal performance and longevity

Emissions Note

This product is a specialized alignment tool and does not impact vehicle emissions or legality. It is intended solely for use during clutch installation and does not alter any emissions systems or regulations.
