ACT Alignment Tool

1988 Toyota Camry / 1999–2006 Toyota Solara, 2005–2010 Scion tC, 2008–2015 Scion xB, 2009–2012 Toyota Corolla, 1996–2000 Toyota RAV4, 1990–1991 Lexus ES250

Part #: AT71

Overview

The ACT Alignment Tool AT71 is an essential accessory for anyone installing or replacing a clutch on compatible Toyota and Lexus models. Designed specifically to assist with the precise alignment of the clutch disc during installation, this tool ensures that the clutch assembly is perfectly centered with the pilot bearing and input shaft. Proper alignment is critical for smooth engagement, preventing damage to the transmission and ensuring optimal clutch performance. Whether you're a professional mechanic or a dedicated DIY enthusiast, the ACT Alignment Tool simplifies the clutch installation process, saving you time and reducing frustration.

Constructed with durability and precision in mind, this alignment tool is compatible with a wide range of vehicles, including the Toyota Camry, Solara, RAV4, Corolla, and Lexus ES250, spanning model years from 1988 through 2015. Its compact design and lightweight construction make it easy to handle and store, while its robust materials ensure reliable performance through multiple uses. Using the ACT AT71 will help you achieve a professional-level installation, ensuring your vehicle's clutch system functions flawlessly and prolongs the lifespan of your clutch components.

Key Features

The ACT Alignment Tool AT71 offers several key features that make it an indispensable part of your clutch installation toolkit:

• Precision Fit: Designed specifically for Toyota and Lexus models listed, ensuring accurate alignment of the clutch disc with the pilot bearing and input shaft.
• Durable Construction: Made from high-quality materials that withstand the stresses of repeated use, providing long-lasting reliability.
• Lightweight Design: Weighing only 0.1 lbs., it is easy to handle and maneuver during installation.
• Universal Compatibility: Suitable for various models including Toyota Camry, Solara, RAV4, Corolla, and Lexus ES250, covering a broad range of years and applications.
• Ease of Use: Simplifies the clutch alignment process, reducing installation time and minimizing the risk of misalignment-related issues.
• Compatibility with Spline Quantity: Designed to fit spline quantities of 21, ensuring proper engagement with the clutch disc.
• Input Shaft Diameter: Compatible with input shafts measuring 1.125 inches in diameter, matching the specifications of the listed vehicles.

Construction & Design

The ACT Alignment Tool AT71 features a precisely machined, high-strength construction that guarantees a perfect fit for the specified vehicle applications. Its compact, lightweight design makes it easy to insert and remove during clutch assembly. The tool's durable materials resist wear and deformation, ensuring consistent performance over multiple uses. Its straightforward design allows for quick and accurate alignment, which is crucial for a smooth clutch operation and long-term reliability of your vehicle's drivetrain.

Installation & Fitment

Using the ACT Alignment Tool AT71 is straightforward and enhances the efficiency of your clutch installation process. Simply insert the tool into the flywheel or pressure plate, align the clutch disc with the pilot bearing, and then proceed with tightening the pressure plate. The tool holds the clutch disc in the correct position, preventing it from shifting during assembly. No additional tools or modifications are required, and the process does not involve any cutting or drilling. Its compatibility with a wide range of Toyota and Lexus models makes it a versatile addition to your repair kit.

• Insert the alignment tool into the flywheel or pressure plate.
• Align the clutch disc with the pilot bearing using the tool as a guide.
• Secure the pressure plate over the clutch disc, ensuring proper centering.
• Tighten the pressure plate bolts evenly to complete installation.

With the ACT AT71, you can confidently perform clutch replacements with a professional-level result, ensuring smooth operation and longevity of your vehicle's clutch system.

What's Included

• ACT Alignment Tool AT71

Ideal For

• DIY enthusiasts performing clutch replacements on Toyota and Lexus vehicles
• Professional mechanics seeking a reliable alignment tool
• Anyone looking to ensure precise clutch disc alignment during installation

Emissions Note

This product is a specialized tool for clutch installation and does not impact vehicle emissions or legality. It is intended for use in standard repair and maintenance procedures.
