ACT Alignment Tool

1966–1970 Ford Fairlane, Galaxie 500, Torino, Mustang

Part #: ATFL10

Overview

The ACT Alignment Tool ATFL10 is an essential accessory designed to simplify the installation of ACT pressure plates on a variety of classic Ford vehicles. Whether you're a professional mechanic or a dedicated enthusiast restoring or upgrading your vehicle, this alignment tool ensures precise positioning of the clutch disc during assembly. Its straightforward design helps you achieve perfect alignment with the pilot bearing and transmission input shaft, reducing installation time and preventing common misalignment issues that can lead to clutch chatter or uneven wear.

Constructed for durability and ease of use, the ACT Alignment Tool is ideal for those working on Ford models from the mid-1960s to the early 1970s, including the Ford Fairlane, Galaxie 500, Torino, and Mustang. It provides a reliable, repeatable method for aligning clutch components, ensuring your vehicle's drivetrain functions smoothly and efficiently after installation.

Key Features

The ACT Alignment Tool ATFL10 offers several features that make clutch installation more straightforward and accurate:

• Precise Fitment: Designed specifically for Ford models from 1963 to 1970, including the Ford Fairlane, Galaxie 500, Torino, and Mustang, ensuring a perfect fit for these applications.
• Easy Alignment: Facilitates correct alignment of the clutch disc with the pilot bearing, preventing misalignment that can cause vibration or uneven clutch wear.
• Durable Construction: Made from high-quality materials that withstand repeated use in a workshop or garage setting, ensuring longevity and reliable performance.
• Lightweight Design: Weighing only 0.1 lbs., this tool is easy to handle and store, making it convenient for both professional and DIY use.
• Universal Compatibility: Features a 1.375-inch input shaft diameter and 10 spline quantity, compatible with a wide range of clutch assemblies for the specified vehicles.
• Time-Saving: Reduces installation time by providing a quick and accurate method for aligning clutch components, minimizing frustration and ensuring proper engagement.
• Cost-Effective Solution: An affordable accessory that enhances the quality of your clutch installation process, helping to prevent costly rework or damage.

Construction & Design

The ACT Alignment Tool ATFL10 is crafted from high-strength, durable materials designed to withstand the rigors of automotive repair. Its compact and lightweight design makes it easy to handle during clutch assembly, while its precise dimensions ensure accurate alignment every time. The tool features a 1.375-inch input shaft diameter with 10 splines, matching the specifications of many classic Ford clutch assemblies. Its simple yet robust construction guarantees consistent performance, whether used in a professional shop or a home garage.

Installation & Fitment

Using the ACT Alignment Tool ATFL10 is straightforward and requires no special tools or skills. Simply insert the tool into the clutch disc's center, aligning the splines with the input shaft of the transmission. This ensures the clutch disc is perfectly centered, allowing for effortless installation of the pressure plate and transmission. The process helps prevent common issues such as misalignment or uneven clutch wear, leading to smoother operation and longer component life. No cutting, drilling, or additional modifications are necessary, making it a hassle-free addition to your clutch installation kit.

What's Included

• ACT Alignment Tool ATFL10

Ideal For

• Automotive enthusiasts restoring classic Ford models from 1963 to 1970
• Professional mechanics performing clutch replacements on Ford Fairlane, Galaxie 500, Torino, and Mustang
• DIYers seeking a reliable tool to ensure precise clutch alignment during installation

Emissions Note

This product is a specialized alignment tool and does not impact emissions or legal compliance. It is intended solely for use during clutch installation and does not alter vehicle emissions systems or regulations.
