• ACT XT/Race Sprung 6-Pad Clutch Kit | BMW M3 E46 (01-06) (BM9-XTG6)
1 1

ACT XT/Race Sprung 6-Pad Clutch Kit | BMW M3 E46 (01-06) (BM9-XTG6)

ACT XT/Race Sprung 6-Pad Clutch Kit | BMW M3 E46 (01-06) (BM9-XTG6)

BM9-XTG6

Out of stock

$986.00 USD
$1,217.00 USD $986.00 USD
kADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The ACT XT/Race Sprung 6-Pad Clutch Kit for the BMW M3 E46 (2001-2006) is a high-performance clutch system designed for demanding driving conditions. Featuring an Xtreme pressure plate, this kit provides increased clamp load and reduced deflection, making it ideal for aggressive street and race applications. The clutch disc utilizes ACT's 6-pad spring-centered race design, ensuring durability and consistent engagement. All components undergo a four-stage heat-treating process, enhancing heat resistance and longevity. Precision cover stampings on the pressure plate deliver added rigidity and stability, resulting in improved power transfer and clutch feel during intense driving.

This clutch kit is specifically engineered for the BMW M3 E46 equipped with the original engine configuration within the 2001-2006 model years. It serves as a direct replacement or performance upgrade for stock clutch components, suitable for track days, spirited driving, or high-performance street use. Installation involves bolt-on replacement of the existing clutch assembly, with all necessary components included in the kit. Designed to withstand high torque loads and aggressive driving styles, this clutch system ensures reliable performance and long-lasting durability for enthusiasts seeking maximum performance from their vehicle.

Overview

2001-2006 BMW M3 E46 XT/Race Sprung 6-Pad Clutch Kit by ACT

BM9-XTG6 kit features an Xtreme pressure plate for the most demanding driver, and ACT's 6 pad spring-centered race disc.

ACT Xtreme pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency.

ACT's 6-pad, spring-centered race disc features a spring-center to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad, spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad, spring-centered disc is recommended for larger clutch sizes to absorb more heat.

ACT clutches deliver the maximum holding power through applying a series of sound engineering advancements to new — not rebuilt — components that maximize load and reduce flex. The result is maximum torque capacity, long life and clean, fast shifting.

Features

  • Feel: Moderate to heavy pedal effort, aggressive engagement, OE to mild gear rattle
  • Life: Moderate friction life, extended by ACT's exclusive diaphragm design
  • Quality: Carefully engineered, precisely assembled, accurately balanced, uses select ceramic friction materials for high heat tolerance and maximum performance.
  • Recommended Use: Recommended for high horsepower street or race use
  • ACT Difference: 100% clamp load tested and dynamically computer balanced for smooth high RPM reliability

Please Note: California Residents - Prop 65 Warning.

Applications

  • 2001 - 2006 BMW M3 (E46)

Specifications

  • Disc Type: Sprung 6-Pad Race Disc
  • Disc Material: Ceramic
  • Pressure Plate Type: Xtreme
  • Torque Capacity Over OE: 129%
  • Torque Capacity (ft/lbs.): 702

What's In The Box?

  • 1 - Xtreme Pressure Plate
  • 1 - Sprung 6-Pad Race Disc
  • 1 - Alignment Tool
  • Applicable Bearings

References

Warranty

  • ACT 1-Year Limited Warranty
