ACT XT/Race Sprung 6 Pad Clutch Kit | Subaru BRZ / Toyota 86 / Scion FR-S (13-20) (SB7-XTG6)

ACT XT/Race Sprung 6 Pad Clutch Kit | Subaru BRZ / Toyota 86 / Scion FR-S (13-20) (SB7-XTG6)

SB7-XTG6

In stock

$946.00 USD
$1,168.00 USD $946.00 USD
kADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The ACT XT/Race Sprung 6 Pad Clutch Kit SB7-XTG6 is a high-performance clutch assembly designed for demanding driving conditions. Featuring an Xtreme pressure plate, this kit provides increased clamp load, reduced deflection, and extended clutch life. The pressure plate employs an exclusive diaphragm design, which undergoes a four-stage heat-treating process to ensure durability and consistent performance. The 6-pad spring-centered race disc is engineered to deliver precise engagement and smooth power transfer, making it suitable for aggressive street and track use. Constructed with high-quality materials, this clutch kit offers reliable performance under high-stress conditions, making it an ideal upgrade for enthusiasts seeking maximum holding capacity and longevity.

Designed for Subaru BRZ, Toyota 86, and Scion FR-S models from 2013 to 2020, this clutch kit is a direct replacement for stock components. It is compatible with vehicles equipped with manual transmissions and is intended for high-performance applications, including spirited driving and racing. The kit includes all necessary components for installation, ensuring a straightforward upgrade process. Suitable for street, track, and competitive use, this clutch assembly enhances vehicle responsiveness and durability. Proper installation ensures optimal performance, making it an excellent choice for drivers seeking a reliable, high-capacity clutch solution.

Overview

ACT XT/Race Sprung 6 Pad Kit

SB7-XTG6 kit features an Xtreme pressure plate for the most demanding driver. ACT Xtreme pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency. ACT's 6-pad spring-centered race disc features a spring-center construction to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad spring-centered disc is recommended for larger clutch sizes to absorb more heat.

Features

  • Part Fitment Requirement: Conversion kit. Includes ACT Streetlite flywheel. Must use ACT flywheel (included in kit).
  • Product Weight (lbs.): 26.6
  • Torque Capacity (ft/lbs.): 449
  • Torque Capacity Over OE: 1.66
  • Flywheel Included: Yes
  • Pressure Plate Type: Xtreme
  • Release Bearing Included: Yes
  • Clutch Disc Diameter (in.): 8.8
  • Clutch Disc Diameter (mm): 224
  • Disc Material: Ceramic
  • Input Spline Quantity: 24
  • Input Shaft Diameter (in.): 1
  • Alignment Tool Included: Yes

Applications

  • 2017-2020 Toyota 86
  • 2013-2020 Subaru BRZ
  • 2013-2016 Scion FR-S

What's In The Box?

  • Clutch Flywheel (600705)
  • Clutch Friction Disc (6224218-1)
  • Clutch Alignment Tool (AT90)
  • Clutch Pilot Bearing (PB1004)
  • Clutch Release Bearing (RB004)
  • Clutch Pressure Plate (SB017X)

References

Warranty

  • Manufacturer 1 Year Warranty
