Aeromotive Replacement 40 Micron Fabric Element (12603)

Name: Aeromotive Replacement 40 Micron Fabric Element (12603)
Brand: Aeromotive
Price: 29.47 USD
Availability: InStock

Aeromotive Replacement 40 Micron Fabric Element (12603)

SKU:12603

In stock

$29.47 USD

~~$33.40 USD~~ $29.47 USD

kADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

Product variants

Quantity

The Aeromotive Replacement 40 Micron Fabric Element (12603) is a high-quality stainless steel filter element designed for use with ORB-10 filter housings. Constructed from 100-micron stainless steel mesh, this filter ensures efficient removal of contaminants from the fuel system, helping to maintain optimal fuel flow and engine performance. Its durable design resists corrosion and provides reliable filtration, reducing the risk of clogging and engine damage caused by debris or dirt accumulation. Regular replacement or cleaning of this filter element is essential for preventing fuel system issues and ensuring consistent engine operation, especially in high-performance or demanding applications.

This filter element is compatible with Aeromotive's ORB-10 filter housings and is suitable for a wide range of fuel systems requiring 40-micron filtration. It is ideal for use in street, race, or off-road vehicles where fuel purity is critical. The replacement part is straightforward to install, serving as a direct upgrade or replacement for existing filter elements. Proper maintenance of this filter helps extend the lifespan of fuel pumps and injectors, ensuring peak performance and reliability in various automotive setups.

Overview

100-M Stainless Element: ORB-10 Filter Housings by Aeromotive Inc.

Commonly the most overlooked component in a fuel system, filter neglect can be the most costly. If not cleaned or replaced regularly, filter elements can become clogged resulting in reduced fuel flow, engine performance and ultimately, fuel pump or even worse, engine damage. By simply replacing and/or cleaning your filter elements regularly, you can avoid costly repairs to your fuel system and ensure peak engine performance.

Aeromotive recommends annual inspection and service of filter elements. This includes replacing 10-micron fabric elements and cleaning or replacing 100-micron stainless steel elements. Severe duty applications or newly installed systems may require more frequent maintenance.

Features

Direct Replacement Filter Element For Filter P/N’s: P/N 12303, P/N 12353.
Recommended for applications burning pump gas, racing gas, diesel fuel, jet fuel, av-gas, etc.
Approved for use in alcohol fuels including ethanol and methanol.
Over 60-sq. inches of element surface area supports high flow while providing good service life.
Cleanable 100-micron Stainless Steel mesh construction.
Flow capacity of up to 600 plus GPH (10.00 GPM) with less than 1-PSI pressure drop.
Supports up to 5,000 plus Flywheel HP, Forced Induction, on gasoline.
Supports up to 4,000 Flywheel HP, Forced Induction on Ethanol.
Supports up to 2,000 Flywheel HP, Forced Induction on Methanol.
Ideal as a pre-pump filter with gasoline, ethanol and Methanol burning engines with small to medium Aeromotive fuel pumps from the 11109 to the A1000 and the SS series fuel pumps.
Popular as a post pump filter with 12 Series (belt and hex driven) mechanical fuel pumps and Aeromotive Spur Gear Pumps up to 21 GPM.
