AutoMeter Ultra-Lite II 2-1/16in 0-280 Ohm Programmable Fuel Level Gauge (4910)

AutoMeter Ultra-Lite II 2-1/16in 0-280 Ohm Programmable Fuel Level Gauge (4910)

4910

Out of stock

$169.83 USD
$198.08 USD $169.83 USD
kADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The AutoMeter Ultra-Lite II 2-1/16 inch 0-280 Ohm Programmable Fuel Level Gauge is a high-precision instrument designed to provide accurate fuel level readings in a variety of automotive applications. Featuring a digital stepper motor, this gauge offers easy configuration of resistance ranges, simplifying the setup process. It comes with seven factory-stored common configurations, ensuring compatibility with most fuel senders. For applications outside these presets, an innovative custom calibration mode allows users to fine-tune the gauge for precise readings. Constructed with a durable, lightweight design, the gauge ensures reliable performance and long-term durability in demanding conditions.

This programmable fuel level gauge is suitable for a wide range of vehicles and can be customized to match specific sender resistances. It is ideal for street, track, or custom builds where accurate fuel monitoring is essential. The gauge is a direct replacement for standard 2-1/16 inch units and can be installed easily with minimal wiring adjustments. It does not include a fuel sender but is compatible with most 0-280 ohm senders, making it versatile for various fuel systems. Whether for restoration, performance upgrades, or daily driving, this gauge provides precise fuel level information to enhance vehicle operation.

Overview

Traditionally, Paring The Proper Fuel Level Level Gauge To The Application Could Be A More Difficult Task Than It Needed To Be. The Autometer Digital Stepper Motor Fuel Level Gauge Drastically Simplifies The Process With Its Easily Configurable Resistance Range. With 7 Common Configurations Stored In Memory From The Factory, The Vast Majority Of All Applications Are Covered. In The Instance Your Fuel Level Sender Is Not Included In These Preconfigured Ranges, An Innovative Custom Calibration Mode Allows Any Sending Unit That Operates Between 0 And 280 Ohms, Empty Or Full, To Be Easily Paired. Our Snapshot" Programming Method Will Allow You To Capture The Empty And Full Readings And The Gauge Does The Rest. No Matter Your Application, There Simply Isnt An Easier Solution For Fuel Level Monitoring Available On The Market. A Direct Plug In Wiring Harness Is Included For Ease Of Installation.

Features:

  • 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
  • Adjustable Scale w/ 7 preset ranges for common vehicle types (73E/10F, 16E/158F, 0E/30F, 0E/90F, 240E/33F, 107.5E/7F, 131E/12F)
  • Autometers Race Proven Digital Stepper Motor Electric Instruments Provide Unmatched Accuracy Which Is Further Increased By Utilizing A Self Calibration Sequence During Power Up
  • Gauge kit includes 20 ft. wiring harness, mounting hardware, and detailed instructions for installation
  • Modern white LED through-the-dial lighting provides clear visibility during nighttime use
  • User definable resistance setting programmable anywhere between 0-280 ohms
