| Year | Make | Model |
|---|---|---|
| 2007 - 2008 | Ford | F-150 FX2 |
| 2006 - 2008 | Ford | F-150 Harley-Davidson Edition |
| 2005 - 2008 | Ford | F-150 King Ranch |
| 2004 - 2008 | Ford | F-150 Lariat |
| 2008 | Ford | F-150 Limited |
| 2004 - 2008 | Ford | F-150 STX |
| 2008 | Ford | F-150 THE 60TH ANNIVERSARY EDITION |
| 2004 - 2008 | Ford | F-150 XL |
| 2004 - 2008 | Ford | F-150 XLT |
| 2006 - 2008 | Lincoln | Mark LT Base |
Bilstein B8 5100 F&R Shock Absorbers | Ford F-150 07-08 (24-317757) (SPF24317-12K)
Bilstein B8 5100 F&R Shock Absorbers | Ford F-150 07-08 (24-317757) (SPF24317-12K)
SKU:24-317757
In stock
Couldn't load pickup availability
â–¶ Vehicle Fitments
The Bilstein B8 5100 shock absorbers are high-performance, ride height adjustable components designed for the 2007-2008 Ford F-150. These monotube shocks feature a 46mm digressive piston and a self-adjusting deflective disc valve setting, ensuring optimal damping performance. The multiple snap-ring grooves allow for customizable spring seat positions, enabling a front lift of 0 to 3 inches when used with OE springs. Constructed with durable materials, these shocks provide enhanced stability, improved handling, and a smoother ride, making them ideal for trucks requiring adjustable suspension height and superior ride quality.
Designed specifically for 2007-2008 Ford F-150 models with front OE coilover style suspension, these shocks serve as direct replacements or upgrades for stock units. They are suitable for applications involving off-road, towing, or performance driving, offering versatility across various driving conditions. The kit includes the shock absorbers with adjustable mounting positions, allowing for precise height customization. Installation is straightforward for those familiar with suspension components, and these shocks are compatible with vehicles equipped with OE springs, providing a reliable upgrade for improved load handling and ride comfort.
Share
Overview
Overview
Bilstein B8 5100 (Ride Height Adjustable) Shock Absorbers for the 2007-2008 Ford F-150 are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube Shock Absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) Shock Absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) Shock Absorber is the easiest way to level out your vehicle.
Standard Features
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
- Adjustable spring seat offers 0-2.75in of lift, depending on the application
Specifications
| Part Number | 24-317757 |
| Part Name | Shock Absorber |
| Vehicle | 2007-2008 Ford F-150 |
| UPC | 651860901435 |
| Front Lift Height | 0 - 2 in. |
| Body Design | Snap Ring Grooved Body (Coilover) |
| Body Diameter (ID) | 46 mm |
| Boot Included | No |
| Collapsed Length | 15.37 in. |
| Collapsed Length | 390.5 mm |
| Damping Adjustable | No |
| Extended Length | 20.97 in. |
| Extended Length | 532.7 mm |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 20.3 mm |
| Reservoir | No |
| Segment | Light Truck |
| Series | B8 5100 (Ride Height Adjustable) |
| Spring Seat Included | Yes |
| Upper Mount Type | Stem |
Vehicle Fitment
- 2007 Ford F-150
- 2008 Ford F-150
