Bilstein B8 8112 ZoneControl CR Coilover | FJ Cruiser (07-09) (41-326336)

Bilstein B8 8112 ZoneControl CR Coilover | FJ Cruiser (07-09) (41-326336)

SKU:41-326336

Out of stock

Regular price $1,160.00 USD
Regular price $1,264.85 USD Sale price $1,160.00 USD
kADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The Bilstein B8 8112 ZoneControl CR Coilover for the 2007-2009 Toyota FJ Cruiser is a high-performance suspension component designed to enhance off-road and on-road handling. Engineered with ZoneControl technology, this coilover features a triple piston design that provides three stages of compression damping and two stages of rebound damping, allowing for precise adjustment based on driving conditions. Constructed with durable materials, it offers position-sensitive damping that adapts to various terrains and load conditions, ensuring optimal ride quality and stability. The threaded spring seat allows for ride height adjustments from 0 to 3.8 inches, enabling customization for different driving preferences and applications. This coilover kit is built to deliver improved control, comfort, and durability for demanding off-road adventures or daily driving.

Designed specifically for the 2007-2009 Toyota FJ Cruiser, this direct-fit coilover is suitable for models equipped with light truck and SUV chassis. It is intended for use in off-road, trail, and street driving scenarios, providing a versatile upgrade over stock suspension components. Installation is straightforward as a bolt-on replacement, with the kit including the coilover assembly ready for mounting. The ZoneControl CR system ensures adaptive damping performance, making it ideal for drivers seeking enhanced handling and ride quality across varied terrains. Compatibility is limited to the specified model years and vehicle configurations, ensuring a precise fit and reliable performance.

Overview

Bilstein B8 8112 (ZoneControl) CR Suspension Kit for the 2007-2009 Toyota FJ Cruiser are a direct fit, position sensitive coilover designed for light trucks and SUV's. ZoneControl CR is a revolutionary technology delivering position sensitive damping. The system incorporates a triple piston design, offering 3 stages of compression valving and 2 stages of rebound valving. The coilover module utilizes a threaded spring seat for ride height adjustability ranging from 0-3.8 (depending on application). The coilover is supplied with a remote reservoir for increased cooling and an accompanied, bolt-on anodized reservoir chassis mount. BILSTEIN B8 8112 (ZoneControl) CR position sensitive coilovers will offer unparalleled ride comfort during every day driving combined with maximum control over large suspension inputs.

Standard Features

  • ZoneControl CR: Position sensitive damping with 3 compression zones and 2 rebound zones, controlled by 3 independent pistons
  • Triple piston design delivers comfort during every day driving conditions and maximum control under large suspension inputs
  • 60mm remote reservoir for increased oil capacity and cooling
Specifications
Part Number 41-326336
Part Name Shock Absorber and Coil Spring Assembly
Vehicle 2007-2009 Toyota FJ Cruiser
UPC 651860916767
Front Lift Height 1.3 - 3.4 in.
Body Design Smooth Body (Coilover)
Body Diameter (ID) 60 mm
Body Material Steel
Boot Included No
Collapsed Length 17.99 in.
Collapsed Length 456.9 mm
Damping Adjustable No
Extended Length 22.80 in.
Extended Length 579.1 mm
Finish Dampers: EVO Grey / Springs: Black
Internal Design Monotube
Lower Mount Type Eye 14.1 mm
Optional Heavy Load Springs 53-291387, 53-332837
Reservoir Yes
Segment Light Truck
Series B8 8112 (ZoneControl CR)
Spring Seat Included Yes
Upper Mount Type Special
Notes Without X-REAS Suspension
Vehicle Fitment
  • 2007 Toyota FJ Cruiser
  • 2008 Toyota FJ Cruiser
  • 2009 Toyota FJ Cruiser
