Cusco Street Zero-A 40-Way Adjustable Coilovers | Toyota Prius (ZVW50) (17+) (1A1 62N CN)

Cusco Street Zero-A 40-Way Adjustable Coilovers | Toyota Prius (ZVW50) (17+) (1A1 62N CN)

1A1 62N CN

Out of stock

$1,680.00 USD
$2,100.00 USD $1,680.00 USD
kADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The Cusco Street Zero-A coilovers are a high-performance suspension upgrade designed for the Toyota Prius (ZVW50) models from 2017 onward. These coilovers feature a full-length adjustable vehicle height system, allowing precise lowering and customization of ride height to suit individual preferences. With damping force adjustable in 40 steps, they enable fine-tuning for optimal ride comfort and handling performance across various street conditions. Constructed with durable materials and equipped with standard upper mounts (except models with upper mountless structures), these coilovers deliver a balance of comfort, quietness, and sporty responsiveness. They are engineered to enhance the vehicle's stance while maintaining a smooth, controlled ride, making them suitable for daily driving and spirited street use.

Designed specifically for 2017+ Toyota Prius (ZVW50), these coilovers are a direct bolt-on upgrade that replaces the factory suspension components. They are compatible with models equipped with genuine rubber upper mounts, providing an easy installation process. The full-length height adjustment feature allows users to set their preferred ride height without compromising comfort or handling. Ideal for street enthusiasts seeking a lowered stance with customizable damping, these coilovers improve both aesthetics and driving dynamics. They are suitable for street use, offering a quiet, comfortable ride while providing the performance benefits of adjustable damping and height control.

Overview

Low-down ride comfort and quietness are top-level. "Damping force 40-step adjustment" and "full-length adjustable vehicle height adjustment" provide optimal ride comfort regardless of the amount of low-down and fine-tuned vehicle height adjustment of the street series.

  • 40 steps of damping force adjustment
  • Full length adjustable vehicle height adjustment
  • Upper mount standard equipment (except models with upper mountless structure)
  • The minivan is standard equipped with a genuine shape rubber upper mount with high quietness.
  • Adopted CPRV (Pressure Control Valve)
  • Silent design that suppresses the operating sound (squeaky sound) of damping adjustable shocks
  • Compatible with e-con2 (Applicable models only)

Damping force (ride comfort) 40-stage adjustable type that clearly shows the difference

  • With a wide damping force adjustment range and uniform damping changes from 1 to 40 steps, you can easily adjust the ride comfort to your liking in any situation or stage. In addition, the knurled dial eliminates the need for tools for damping adjustment.

Full length adjustable vehicle height adjustment

  • "Overall length adjustment type" that does not change the suspension stroke even if the vehicle height is lowered. Both fine vehicle height adjustment and high ride comfort are achieved.

Upper mount standard equipment

  • Dedicated upper mount is standard equipment. By equipping the minivan with a quiet genuine rubber upper mount as standard equipment, we have achieved even greater comfort and improved workability by eliminating the need to change the upper mount from the genuine shock.

Adoption of CPRV (Pressure Control Valve)

  • A CPRV (pressure adjustment valve) is adopted to optimize the change width so that the damping force does not drop more than necessary at low speeds. It provides the best ride comfort and high steering stability in all areas from low speed to high speed.

Designed specifically for each model to ensure sufficient bump stroke even when lowered

  • Since it is specially designed for each car model in the lineup, sufficient bump stroke is secured. In addition, we have thoroughly tested everything from a single passenger to a full passenger, and in the case of a minivan, we have made comfortable settings for the third seat.

Adoption of a twin-tube shock provides a mild ride and sufficient stroke

  • A dual-tube structure low-pressure gas shock absorber is used to provide a mild ride. The generous shell case and piston diameter ensure ample oil capacity, and by exhibiting smooth damping characteristics, both a smooth ride and high driving performance are achieved.

e-con2 compatible

  • Compatible with "e-con2" that allows you to adjust the damping force with a single button from the driver's seat. The optimum damping force can be adjusted at any time according to the scene (applicable models only).

Attention to detail

  • "Nickel chrome plating" is used for the adjustment screws to protect them from rust, sand and dust. In addition, we are thoroughly particular about quality, such as inserting a high polymer thrust sheet to prevent the lock nut from loosening and improve quietness.

SPECIFICATIONS:

  • Dumping Force: 40 steps
  • Recommended Ride Height Range (mm): Front -30 to -5; Rear -40 to -15
  • Max Ride Height Range (mm): Front -40 to 0; Rear -45 to -5
  • Default Height (mm): -25 / -30
  • Spring Rate (kgf/mm): Front 5 or (6); Rear 4.5
  • Height Adjust: Front Full-length Adjustable; Rear Threaded spacer
  • Upper mount: Front OEM Shape Rubber Upper Mount; Rear Non-adjustable HD rubber upper mount
