DBA Rear 4000 Series Plain Rotor | Subaru BRZ (13-23) (DBA42663-10)

DBA Rear 4000 Series Plain Rotor | Subaru BRZ (13-23) (DBA42663-10)

DBA42663-10

Out of stock

$155.41 USD
$264.19 USD $155.41 USD
kADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The DBA Rear 4000 Series Plain Rotor for Subaru BRZ (2013-2023) is a high-performance brake component designed to enhance stopping power and durability. Constructed from high-quality cast iron, these rotors feature a plain finish that ensures effective heat dissipation and resistance to warping under aggressive driving conditions. The 4000 Series rotors are engineered for consistent performance, providing improved brake feel and fade resistance during spirited driving or track use. Their robust design makes them suitable for demanding applications, offering reliable braking performance and longevity.

These rotors are intended for use on Subaru BRZ models from 2013 to 2023, serving as direct replacements or upgrades for stock rear rotors. Due to the variety of brake packages available for this vehicle, precise fitment may require measuring existing brake discs and pads to compare with the provided specifications. Installation is straightforward for those familiar with brake component replacement, and the kit includes the plain rotors only. They are ideal for street performance, track days, or spirited driving, delivering improved braking response and consistency.

Overview



Notes Regarding Vehicle Compatibility:

Vehicle fitment provided in this listing is to be used as a rough guide only and may not actually suit your vehicle. Due to multiple brake packages sometimes being offered by manufacturers it may be necessary to measure your existing brake discs and/or pads and compare with the measurements provided by DBA here:

DBA Part Finder

Click "Part Number Search" tab and input SKU provided above.

Returns/Exchanges will incur restocking and freight fees or may be denied in certain circumstances.





DBA's 4000 Series disc brake rotors are a direct replacement single-piece brake rotor, designed for drivers seeking upgraded performance braking in the Specifications tab and beyond standard OE levels. Cast from XG-150 high carbon alloyed iron and undergoing Thermal Stability Profiling (TSP), DBA's metallurgy is able to handle the increased stress and heat generated under intense braking applications, time and time again.

Featuring DBA's patented Kangaroo Paw ventilation that implements a series of 144 diamond and teardrop patterned pillars, DBA achieves up to a 30% increase in surface area and 20% improvement in cooling efficiency (as compared to a traditional straight vane design).

DBA's 4000 Series HD variant features a smooth OE style rotor finish, popular for drivers looking for the benefits of a 4000 Series rotor but requiring an OE style look, such as under controlled race divisions.



Features (Where Applicable):

Kangaroo Paw 144 diamond and tear drop pillar ventilation system

  • Increased surface area resulting in greater heat dissipation which minimises brake fade and increases braking effectiveness and prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs

XG150 High Carbon Alloyed Iron

  • An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time which minimises warping and cracking and prolongs the service life of the rotor.
  • Special formulation designed to respond to DBA's TSP process.

Thermographic Temperature Monitoring

  • Heat paint markings change colour at specific temperature thresholds offers the driver a clear indication of peak braking temperatures.
  • When temperature thresholds are exceeded paint markings will permanently change colours allowing the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims.

Paint protection on non-friction areas

  • Reduces corrosion, enhances appearance, stops any unsightly rust formation, adds value to the product.





Vehicle Fitment:

To ensure correct compatibility we always recommend comparing your existing brake discs to the measurements provided in the Specifications tab. Vehicle fitment provided is to be used as a guide only and may not suit your vehicle.

  • 2022+ Subaru WRX VB
  • 2012-2021 Subaru BRZ (Non-Brembo)
  • 2022+ Subaru BRZ ZD8 (Non-Brembo)
  • 2010-2014 Subaru Liberty BM/BR GT (Non-Brembo)
  • 2012-2021 Toyota 86 GTS (Non-Brembo)

View full details
