• Fabtech 3.5in BJ Upper Control Arm System w/ Performance Shocks w/ Intrusion Beam Kit | Ford Ranger 4WD (19-20) (K2323)
  • Fabtech 3.5in BJ Upper Control Arm System w/ Performance Shocks w/ Intrusion Beam Kit | Ford Ranger 4WD (19-20) (K2323)
1 2

Fabtech 3.5in BJ UCA & Perf Shocks w/ Intrusion Beam | Ford Ranger 4WD (K2323)

Fabtech 3.5in BJ UCA & Perf Shocks w/ Intrusion Beam | Ford Ranger 4WD (K2323)

K2323

Out of stock

$960.26 USD
$1,128.65 USD $960.26 USD
ADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The Fabtech 3.5-inch BJ UCA & Performance Shocks system is a high-quality suspension upgrade designed specifically for the 2019 Ford Ranger 4WD. This kit enhances the vehicle's ride height, allowing for the installation of slightly larger tires while maintaining a comfortable, stock-like ride. The system features steel spacers that lift the suspension and utilize the factory coilover shocks, ensuring a seamless fit and reliable performance. The upper control arms are engineered to correct front suspension geometry at the increased ride height, promoting proper alignment and handling. Heavy-duty ball joints contribute to durability and consistent performance under off-road or demanding driving conditions, while the design minimizes suspension bind at full droop for improved wheel travel and articulation.

This suspension upgrade is tailored for 2019 Ford Ranger models with 4WD systems, providing a bolt-on solution that does not require extensive modifications. It is ideal for off-road enthusiasts seeking increased ground clearance and improved wheel travel, as well as those wanting to accommodate larger tires for enhanced traction. The kit includes upper control arms with heavy-duty ball joints and performance shocks designed to work together for optimal ride quality and durability. Suitable for both trail and daily driving, this system ensures proper suspension geometry and alignment at the new ride height, making it a reliable upgrade for improving off-road capability and vehicle stance.

Overview

This quality 2019 Ford Ranger Upper Control Arm system is perfect for owners looking to increase ride height to run slightly larger tires than factory. The system will provide additional Wheel travel with no suspension bind at full droop. Lift is accomplished with steel spacers that utilize the factory Coilover shocks for a stock like ride. Fabtech's Upper Control Arms address the geometry of the front suspension with the new ride height for proper align ability. Heavy duty ball joints allow for extended suspension travel to eliminate binding. The system has been designed for proper CV axle angle and plunge thus eliminating the need to reposition the front differential. Included in this system is Fabtech's Offset Intrusion Beam Kit that allows use of 33in tires. The factory Intrusion Beams are located in the front fenderwells, forward and back of the tire. They limit the size of the tire you can install while being an integral part of the front collision safety impact feature of the vehicle. Rather than modifying or removing the Beams for tire clearance, Fabtech provides replacement Offset Intrusion Beams. They are constructed of 1/4in thick steel and are a welded box design for maximum strength. They allow full steer with 33/1250R tires w/ a 5in back space Wheel. Rear lift comes from 1.5in blocks and u-bolts.

Attributes:

  • GTIN: 00674866108066
  • Brand Name: Fabtech

Extended Information:

  • Country of Origin: United States
  • Emissions : Released
  • Life Cycle Status: Available To Order

Packing Information:

  • Quantity of Each: 1
  • Package UOM: EA
  • Dimension: 24 x 18.26 x 15.5 inches
  • Weight: 75 lb
