ICON 2010+ Toyota FJ/4Runner 0-3.5in Stage 8 Suspension System w/Billet Uca

ICON 2010+ Toyota FJ/4Runner 0-3.5in Stage 8 Suspension System w/Billet Uca

K53068

Out of stock

$8,274.17 USD
$8,274.17 USD $8,274.17 USD
ADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The ICON Stage 8 Suspension System for 2010+ Toyota FJ Cruiser and 4Runner is a high-performance upgrade designed for serious off-road enthusiasts and demanding drivers. It features vehicle-specific tuned, extended travel 2.5-inch coilover shocks with CDCV-equipped remote reservoirs, providing exceptional cooling and adjustable damping across 10 compression levels. The system includes ICON-engineered coil springs for improved vehicle feel and handling through the full range of travel. Height adjustability from 0 to 3.5 inches allows for larger wheels and tires, while billet aluminum Delta Joint upper control arms enhance strength, durability, and alignment retention. CNC-machined, anodized rear links with PTFE-lined FK rod ends and greaseable polyurethane bushings improve articulation and reduce deflection. Rear coil springs lift the vehicle by 2 inches for a level stance, complemented by an adjustable rear track bar for proper axle alignment and fitment on KDSS models. The 2.5-inch Aluminum Series Omega remote reservoir shocks offer 28 compression and rebound settings for superior off-road performance and street comfort.

Designed for 2010-2023 Toyota 4Runners and 2010-2014 FJ Cruisers, this bolt-on suspension system is ideal for off-road adventures, daily driving, and vehicle customization. It maintains factory alignment at the lifted height and ensures proper fitment with vehicle-specific components, including coilovers, control arms, and rear links. The kit enhances wheel travel, damping, and articulation, making it suitable for aggressive off-road use while providing a comfortable ride on paved roads. Installation involves replacing stock components with the included coilovers, control arms, and links, offering a comprehensive upgrade for vehicles equipped with KDSS or standard suspension setups. This system delivers increased performance, durability, and adjustability for drivers seeking maximum control and ride quality in challenging terrains.

Overview

ICON Vehicle Dynamics 2010-2023 Toyota 4Runner and 2010-2014 Toyota FJ Cruiser suspension systems are designed with maximum performance and the serious driver in mind. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. This Stage 8 system includes vehicle-specific tuned, extended travel 2.5” coilover shocks featuring CDCV equipped remote reservoirs for exceptional cooling properties and ICON-engineered coil springs for superior vehicle “feel” through the range of travel. The ICON CDC Valve is an externally adjustable valve that restricts oil flow into the reservoir which creates 10 levels of compression damping force ranges. These coilovers are also height adjustable for 0-3.5” of front lift over stock, allowing the use of larger, more aggressive wheel and tire combinations. Billet aluminum Delta Joint upper control arms not only add strength and durability but help retain factory alignment specs, offer on-vehicle caster/camber adjustment, and allow proper wheel alignment at the lift height this system provides. ICON billet aluminum adjustable rear upper and lower links are made from CNC machined 6061 aluminum and anodized for corrosion resistance. These link arm kits feature PTFE-lined FK rod ends and greaseable polyurethane bushings for increased suspension articulation, reduced deflection, and on-vehicle link arm length adjustability. ICON rear coil springs deliver on-road comfort and superior off-road performance with 2” of rear lift height over stock for a level stance front to rear. An adjustable rear track bar is included to provide proper rear axle alignment, improve articulation, and ensure fitment on KDSS equipped 4Runners. The 2.5 Aluminum Series Omega bypass remote reservoir rear shocks’ larger diameter offers outstanding performance off-road and a smooth ride on the street 28 settings of compression and rebound adjustment.

View full details
