| Year | Make | Model |
|---|---|---|
| 1995 - 2004 | Toyota | Tacoma |
1
/
of
1
ICON 95.5-04 Toyota Tacoma 0-3in Stage 4 Suspension System w/Tubular Uca
ICON 95.5-04 Toyota Tacoma 0-3in Stage 4 Suspension System w/Tubular Uca
SKU:K53014
In stock
Regular price
$3,610.35 USD
Regular price
$3,610.35 USD
Sale price
$3,610.35 USD
Unit price
/
per
Couldn't load pickup availability
▶ Vehicle Fitments
The ICON 95.5-04 Toyota Tacoma Stage 4 Suspension System is a high-performance upgrade designed for serious off-road and on-road driving. It features vehicle-specific tuned 2.5-inch coilover shocks with extended travel and remote reservoirs, providing exceptional cooling and damping capabilities. ICON coil springs enhance vehicle feel across the travel range, while height adjustment from 0 to 3 inches allows for larger, more aggressive wheel and tire setups. The kit includes uniball tubular upper control arms to increase droop and extend travel, and a rear Add-A-Leaf Kit that replaces factory overload leaves to lower rear spring rate by approximately 10% and add 1.5 inches of rear lift. ICON’s 2.0 Aluminum Series remote reservoir shocks balance performance front to rear, delivering improved control and ride quality in demanding conditions.
Designed for 1995–2004 Toyota Tacoma models, including 4WD and PreRunner variants, this Stage 4 suspension system is suitable for both street and off-road use. It is a bolt-on upgrade that enhances wheel travel, damping, and vehicle stability, making it ideal for drivers seeking increased capability and ride comfort. The kit includes coilover shocks, coil springs, tubular control arms, and rear leaf springs, providing a comprehensive suspension upgrade. Compatible with models equipped with a range of wheel and tire sizes, this system is perfect for those looking to improve their Tacoma’s performance in challenging terrains or on daily drives.
Share
Overview
Overview
ICON Vehicle Dynamics Toyota Tacoma suspension systems are designed with maximum performance and the serious driver in mind. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. The Stage 4 system includes vehicle-specific tuned 2.5” coilover shocks featuring extended travel & remote reservoir for exceptional cooling properties and ICON-engineered coil springs for superior vehicle “feel” through the range of travel. These coilovers are also height adjustable from 0-3” allowing the use of larger, more aggressive wheel and tire combinations. This Stage 4 kit also includes uniball tubular upper control arms, designed to give you extra droop with the extended travel coilovers. The included rear Add-A-Leaf Kit Installs in place of the factory overload leaves and effectively lowers the rear spring rate by approximately 10% for a more compliant ride while also providing 1.5" of rear lift over stock. ICON 2.0 Aluminum Series remote reservoir rear shocks utilize a vehicle-specific valving that balances the performance of the truck from front to rear. The ICON Vehicle Dynamics 96-04 Toyota Tacoma 4WD/PreRunner Stage 4 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.
