| Year | Make | Model |
|---|---|---|
| 1993 - 2002 | Chevrolet | Camaro |
| 1993 - 2002 | Pontiac | Firebird |
| 1985 - 2005 | Pontiac | Grand Am |
1
/
of
5
UMI Performance 93-02 F-Body Front Upper A-Arm Mounts Adjustable Coil Over Only
UMI Performance 93-02 F-Body Front Upper A-Arm Mounts Adjustable Coil Over Only
SKU:2335
In stock
Regular price
$229.99 USD
Regular price
$229.99 USD
Sale price
$229.99 USD
Unit price
/
per
Couldn't load pickup availability
▶ Vehicle Fitments
The UMI Performance 93-02 F-Body Front Upper A-Arm Mounts Adjustable Coil Over Only are fabricated adjustable mounts designed to facilitate coilover installation on the front of 4th generation Camaros and Firebirds. These direct bolt-in upgrades replace the original GM mounts, enabling seamless conversion to coilovers. The mounts feature precisely angled stand-off tabs compatible with bearing-mounted coilovers, and include spacers for 1-inch or 1-1/4-inch wide bearings. Their unique fabricated design ensures strength without adding unnecessary weight, while three upper a-arm adjustment holes allow for fine-tuning the vehicle’s front suspension. The adjustable holes enable raising or lowering the a-arm mounting point by 3/8 inch, helping to dial in the front roll center height for improved responsiveness and camber gain, which benefits cornering performance. This versatile upgrade is suitable for street, drag, and track applications, especially when paired with UMI’s lower a-arms for a true bearing-to-bearing coilover setup.
Designed for 1993–2002 Chevrolet F-Body models, including Camaro and Firebird, this kit is ideal for enthusiasts seeking improved suspension performance. It replaces the factory mounts with a fabricated, adjustable solution that enhances handling and ride quality. The product is compatible with coilover shocks featuring 1-inch or 1-1/4-inch wide bearings and is intended for use in street, drag, or track environments. Installation is straightforward as a direct bolt-in upgrade, and the kit includes the necessary adjustment holes and spacers. For optimal performance, it is recommended to use these mounts with UMI’s lower a-arms, P/N 2317 or 2314, to achieve a true bearing-to-bearing coilover setup. This upgrade offers precise suspension tuning and durability tested under demanding conditions.
Share
Overview
Overview
When looking to mount a coilover to the front of your 4th generation Camaro or Firebird, look no further than UMI’s new #2335 fabricated adjustable coilover a-arm mounts. The UMI upper a-arm mount is a direct bolt in upgrade that replaces the original GM mount and helps when converting to coilovers. The two stand-off tabs are angled perfectly to attach any bearing mounted coilover. Spacers are included to install coilover shocks with 1” or 1-1/4” wide bearing. UMI’s product features a unique fabricated design that allows the mounts to be strong without adding any extra weight. UMI’s kit is supplied with three upper a-arm adjustment holes for fine tuning the vehicles front suspension. The original factory holes are located at the center and driver has the option to raise or lower the a-arm mounting point 3/8 of an inch. Adjustment holes feature the ability to dial in the front roll center height. Raising the roll center height increases responsiveness and improves camber gain which allows a less aggressive street alignment to perform well when cornering. For street and drag applications choosing the center hole places the a-arm in the factory location. For ultimate performance use with UMI’s lower a-arms P/N 2317 or 2314 to run a true bearing to bearing mounted coilover (no more t-bar). As always, these products are extensively tested on UMI’s test cars in some of the harshest highway and racing environments. This makes them an excellent upgrade for the street cruiser to the road course expert.
