• Wagner Tuning Competition Intercooler Kit | 2015+ Ford Ranger TDCi (200001148)
1 1

Wagner Tuning Competition Intercooler Kit | 2015+ Ford Ranger TDCi (200001148)

Wagner Tuning Competition Intercooler Kit | 2015+ Ford Ranger TDCi (200001148)

200001148

Out of stock

$963.33 USD
$1,020.00 USD $963.33 USD
xADDITIONAL DISCOUNTS APPLIED AT CHECKOUT Sold out

The Wagner Tuning Competition Intercooler Kit for the 2015+ Ford Ranger TDCi is a high-performance upgrade designed to enhance turbocharged engine efficiency and power output. Featuring a competition core with a tube fin design, this intercooler measures 660 mm x 282 mm x 120 mm (stepped), providing a significant increase in cooling capacity. The core's larger frontal surface area, 32% bigger than the stock intercooler, combined with 279% more core volume, ensures improved heat dissipation and reduced intake air temperatures. Constructed from durable aluminum with cast end tanks, this kit offers superior thermal performance and long-lasting reliability, making it ideal for demanding driving conditions.

Designed specifically for 2015-2021 Ford Ranger models equipped with diesel engines, this intercooler kit is a direct bolt-on upgrade that replaces the stock component. It is suitable for both street and performance applications, including tuning and increased boost scenarios. The kit includes the intercooler core, cast end tanks, and necessary mounting hardware for straightforward installation. Compatible with the factory piping and mounting points, this intercooler enhances overall engine performance and efficiency, making it an excellent choice for enthusiasts seeking improved cooling and power in their Ranger TDCi.

Overview

2015-2021 Ford Ranger Intercooler Kit by Wagner Tuning

The WAGNERTUNING high-performance intercooler has got a new competition core (Tube Fin) with the dimensions 660 mm x 282 [254] mm x 120 [65] mm [stepped] / 21,6 Inch x 6,6 [5,5] Inch x 4,7 [3,9] Inch [stepped], which was developed especially for the requirements of the Ford Ranger diesel engine. This high-performance core offers an 32 % larger frontal surface and 279 % more core volume compared to the stock intercooler.

The aluminum cast endtanks were designed in CAD and optimized in CFD simulations (for an ideal internal airflow). An incorporated air baffle inside the intercooler inlet ensure a uniform filling of the intercooler. The result is a excellent cooling property with a minimal back pressure. The newly developed competition high- performance core is very light and provides the adjoining components (for example the watercooler) enough air flow. An optimal cooling effect of the charged air with a significant increase in performance!

An anti-corrosion powder coating with perfect heat-conducting properties protects the WAGNERTUNING intercooler from all environmental influences, so a lasting and optimal cooling effect can be guaranteed. The installation is done by replacing the original intercooler and is easy to perform (plug and play). All our products are subject to a continuous quality monitoring.

Features

  • Aluminum cast endtanks
  • Excellent cooling property
  • Anti-corrosion powder coating

Benefits

  • Minimal back pressure
  • Optimal cooling effect can be guaranteed

Applications

  • 2015-2021 Ford Ranger

What's In The Box?

  • 1 - Intercooler Kit

References

Warranty

  • Manufacturer Standard Warranty.
View full details
