Wilwood Master Cylinder .875" Compact Banjo Outlet
Wilwood Master Cylinder .875" Compact Banjo Outlet
SKU:260-13621
In stock
Couldn't load pickup availability
The Wilwood Master Cylinder .875" Compact Banjo Outlet is a high-performance brake component designed for limited space applications. Featuring a 3/8-24 banjo outlet, this master cylinder offers the output capacity of a full-size unit while maintaining a compact form factor. Its ultra-short 3.37-inch body provides an additional 2.16 inches of clearance between the mounting flange and the fluid outlet, making it ideal for tight installation environments. The cylinder includes a full 1.12-inch piston stroke, ensuring compatibility with most full-size brake systems. Constructed with durable materials, it delivers reliable performance and consistent fluid transfer, making it suitable for racing, street, or custom builds where space is limited.
This master cylinder is compatible with a variety of vehicle setups requiring a compact yet powerful brake component. It features a top-radius 1/8-inch NPT fluid outlet port for easy plumbing connections. Designed for use in custom or limited-space brake systems, it can be installed as a direct replacement or upgrade in applications where space constraints are critical. The kit includes the master cylinder itself, with no additional components specified. Suitable for racing, off-road, or street performance vehicles, this master cylinder provides the necessary stroke and capacity for effective brake modulation in tight-fitting installations.
Share
Overview
Overview
Wilwood Master Cylinder .875" Compact Banjo Outlet
Universal Fitment
Part #: 260-13621
Overview
The Wilwood Master Cylinder .875" Compact Banjo Outlet is a high-performance brake component designed for racing and custom automotive applications where space is limited. This compact master cylinder combines reliable fluid control with a streamlined design, making it ideal for race cars, hot rods, and custom builds that demand precise braking performance in tight spaces. Its innovative construction ensures consistent pedal feel and responsiveness, supporting your vehicle’s braking system with durability and efficiency. Whether you're upgrading an existing setup or building a custom brake system, this master cylinder offers the performance and fitment flexibility you need.Key Features
This master cylinder features a robust construction and thoughtful design to optimize brake performance and ease of installation:- Compact body measures just 3.37" in length for maximum clearance in tight engine bays or chassis areas
- High-quality aluminum construction for strength and corrosion resistance
- 3/8-24 banjo outlet fitting for versatile brake line connections
- 1.12" piston stroke provides ample travel for effective brake modulation
- Top-radius fluid outlet port with 1/8" NPT thread for secure and leak-free connections
- Designed to meet or exceed the performance standards of full-size master cylinders
- Lightweight yet durable, suitable for high-performance applications
Construction & Design
Constructed from high-grade aluminum, this master cylinder is engineered for durability and corrosion resistance. Its compact, ultra-short body design maximizes clearance without sacrificing strength or fluid capacity. The banjo outlet is precisely machined for a secure fit, ensuring reliable fluid flow and minimal leakage. The piston and internal components are designed to provide consistent pedal feel and responsiveness, supporting precise braking control under demanding conditions.Driving Feel & Feedback
This master cylinder helps deliver a firm, predictable brake pedal feel, enhancing driver confidence and control. Its design ensures smooth, responsive braking action, making it suitable for high-performance driving scenarios where precise modulation is critical.Installation & Fitment
Installation involves mounting the compact master cylinder in the designated space, connecting the brake lines via the banjo outlet, and ensuring proper fluid routing. Due to its small size, verify fitment against your vehicle’s chassis and brake system layout to ensure compatibility.What’s Included
The package includes the Wilwood Compact Master Cylinder with the .875" bore and the necessary fittings for installation. Additional hardware or mounting brackets are not included and should be sourced separately based on your specific application.
